Feature
Self-suction requests on an extra pump to feed it.
High efficiency up to 95%.
Great painting works inside for longer service life under corrosive condition.
Many options for standard or certification: IECEX, ATEX, UL, DGMS, CE, and so on.
Compact and small footprint
It can work as a powerful drilling fluid agitator
Specification
Model |
ZCQ240 |
ZCQ270 |
ZCQ300 |
ZCQ360 |
Max. Capacity |
240m³/h |
270m³/h |
300m³/h |
360m³/h |
Ratio |
1.68 |
1.68 |
1.68 |
1.72 |
Efficiency |
≥95% |
≥95% |
≥95% |
≥95% |
Main Motor |
15KW |
22KW |
30KW |
37KW |
Pump Motor |
2.2KW |
3KW |
4KW |
5.5KW |
Speed |
860rpm |
870rpm |
876rpm |
880rpm |
Dimension |
1750×900×1510mm |
1950×1010×1680mm |
2250×1235×1650mm |
2400×1500×1900mm |
Weight |
1200kg |
1450kg |
1960kg |
2510kg |
