BETTER Drilling Fluid Equipment Industrial Limited

BETTER Self-priming Pump

BETTER Self-priming Pump BETTER Self-priming Pump BETTER Self-priming Pump BETTER Self-priming Pump
Product name : BETTER Self-priming Pump
Item : BT-ZXB
Country of Origin :
Brand Name :
Standard :
Packing Details :
             [Next Product]→

Details:

BETTER Self-priming Pump



BETTER could supply Self-priming centrifugal pumps for clean water, chemicals, sewage and oil.

Standard self-priming pump units are available for solids handling or clear liquid service. Typical mounting configurations are Engine Driven for Skid or Trailer Mounted packages and Frame Mounted Electric Driven. Pumps also are available in a variety of different metallurgies.

 Main Character

1. Beautiful shape and fine structure, reliable performance.

2. With strong capacity of self priming, no need to equip with flap valve.

3. Non-clog, and with powerful capacity of passing big solid.

4. The hole can make sure that stronger sewage can be cleaned quickly when pump is jammed.

5. The unique lubrication oil mechanical seal cavity makes the performance more reliable.

6. Special check valve structure can make the pump working quickly.

7. When working, the gas and liquid works together.

8. Low rotary speed, reliable operation, long time usage, easy to maintenance.

9. Advanced pressure protector makes pump the pump work safe.



Application

 Construction, Industrial, Municipal, Agricultural, Sewage, Dewatering, Mining, Oil Field, Petrochemical



Parameters

Inlet/Outlet:2''(50mm), 3''(75mm), 4''(100mm), 6''(150mm), 8''(200mm), 10''(250mm), 12''(300mm)

Impeller Diameter: 158.74mm-457.2mm

Rotary Speed: 550RPM-2150 RPM

Flow Rates: 8m3/h-1275m3/h   20GPM-5500GPM

Head: 6m-63m

Horsepower: 1HP-125HP

Solid Passing: 20.63mm-76.2mm

Material: Cast Iron, ADI, CD4MCU, 316 SS, Alloy 20, C276.

Diesel Driving: Water cooled or air cooled

Method of Connection: basic units or flex-coupled, V-belt driven or engine mounted.

Drive Variation  Cummins, Deutz, Ricardo, Perkins or Chinese Diesel, Electric Motor

Skid Mounted on Trailer       2 or 4 wheels Trailer/Trailor, Cart



Mounting Configuration

Frame Mounted

Base Mounted Electric Driven

Engine Driven SAE Mounted

Engine Driven Skid or Trailer Packages

Horizontal or Vertical V-Belt Driven
