Product name : BETTER SHALE SHAKER
Item : BT-DFC-5
Country of Origin :
Brand Name :
Standard :
Packing Details :


Details:



BETTER SHALE SHAKER

BETTER shale shakers are special designed and manufactured with the advantages of high vibration intensity, large screen area, adjustable discharge angle during drilling, simple compact structure and cost effective.

Tandem shale shaker and Triple combination shale shaker could be provided. According to the customers’ request, linear motion shale shaker and balanced elliptical motion shale shaker as optional. High strength alloy material SS304 or Q345 is adopted.



Model

BT-ZS280-3P

BT-ZS240-3P

BT-ZS220-3P

BT-ZS180-2P

Vibrating motion

Linear motion or Balanced elliptical motion

Motor power

2×2.2 kW

2×2.2 kW

2×2.2 kW

2×1.3 kW

Screen area(m2)

2.8 m2

2.4 m2

2.2 m2

1.8 m2

Screens of Deck

3 Panel

3 Panel

3 Panel

2 Panel

Shaking intensityg

7.2 g

7.2 g

7.2 g

7.2 g

Discharge capacity

42 l/s

35 l/s

30 l/s

26 l/s

Deck adjustable range

-1°+5.5°

-1°+5.5°

-1°+5.5°

-1°+5.5°

Normal motor power

380v/50hz, 460v/60hz or customized

Overall dimension, mm

3148×1820×1680

2760×1820×1600

2620×1820×1600

2280×1680×1480

Weight

2120 kg

2080 kg

1950 kg

1890 kg

Remarks

Treating capacity test from mud:1.2g/cm3, viscosity 45s, API40 screen mesh



Please consult with our sales for further information.
