SPD MUD HOG 2.5 STYLE CENTRIFUGAL PUMPS
BETTER SBSPD series
Centrifugal Pump is designed equivalent to BAKER SPD MUD HOG 2.5 Centrifugal Pumps. Typical Configuration: 2×3×13， 3×4×13， 4×5×14， 5×6×11， 6×8×11, 6×8×14, 8x10x14.
Common applications,
· Fresh water
· Sea water
· Drilling Mud
Parameters
|
Model |
6×8×14 |
6×8×11 |
5×6×14 |
5×6×11 |
4×5×14 |
3×4×13 |
2×3×13 |
|
Discharge capacity |
240～260 m3/h |
220～240 m3/h |
200～220 m3/h |
120～200 m3/h |
80～120 m3/h |
60～80 m3/h |
50～60m3/h |
|
Pump Head |
28～33m |
24～28m |
24～28m |
24～28m |
24～28m |
22～28m |
22～28m |
|
Efficiency |
65% |
65% |
65% |
65% |
65% |
65% |
65% |
|
Motor power |
55/75 kW |
37/45 kW |
37/45/55 kW |
30/37/45 kW |
18.5/22/30 kW |
11/15 kW |
7.5/11 kW |
|
Motor speed |
1450/1750rpm |
1450/1750rpm |
1450/1750rpm |
1450/1750rpm |
1450/1750rpm |
1450/1750rpm |
1450/1750rpm |
· Size from 3 x 2 x 13 to 10 x 8 x 14
· Head pressure up to 550 feet
· Best utilized requiring up to 200HP
· Revolutionary design on Baker SPD Mud Hog2.5 series
· Improved stability, lower vibration, cost saving
· Thick, strong, concentric casing with replaceable wear pad
· Wide semi-open impeller creates lower axial trust for improved the life of bearing, mechanical seal and stuffing box
· Available in hard iron, stainless steel, high chrome alloy and aluminum bronze fluid ends
· Available to be driven by electric motor, diesel engines, hydraulic motors
|
QTY EA |
DESCRIPTION |
MAT. |
BETTER |
SPD |
USA BRAND |
USA BRAND |
|
1 |
Casing |
Hard Iron |
See below |
See below |
See below |
See below |
|
1 |
Gasket, casing |
Fiber |
BT-052137100 |
052137100 |
G0006034 |
720700 |
|
12 |
Nut, casing 3/4-10 hex head |
Stl., |
BT-WWJ11S800 |
WWJ11S800 |
G0006032 |
720860 |
|
12 |
Stud, casing 3/4-10 x 3 1/4”long |
Stl., |
BT-WWHS1S3HA |
WWHS1S3HA |
G0006032 |
720830 |
|
1 |
Plug, casing drain |
Stl |
BT-WWWX00012 |
WWWX00012 |
|
721651 |
|
1 |
Impeller |
Hard Iron |
See below |
See below |
See below |
See below |
|
1 |
Seal, impeller |
Viton |
BT-WWB032V35 |
WWB032V35 |
G0006035 |
721480 |
|
1 |
Bolt,impeller lock |
Stl |
BT-WWGL1S203 |
WWGL1S203 |
|
721402 |
|
1 |
Stuffing box,mech.seal |
Hard Iron |
BT-052136410 |
052136410 |
G0006017 |
721350 |
|
1 |
Stuffing box, packed |
Hard Iron |
BT-052144910 |
052144910 |
G0006016 |
721340 |
|
2 |
Bolt, stuffing box 1/2-13 x 1 1/4” |
Stl |
BT-WWG31H187 |
WWG31H187 |
|
721400 |
|
1 |
Gland assy., packing |
Stl. 304 |
BT-052136500 |
052136500 |
G000604 |
720590 |
|
1 |
Seal, mechanical |
Tungst.Carbide |
BT-WVBUF9000 |
WVBUF9000 |
G0006013 |
721540 |
|
3 |
Packing,Shaft-M.S.Backup 3 Rings |
Teflon |
BT-052141500 |
052141500 |
|
720441 |
|
1 |
Graphite Packing,Shaft-w / Lantern ring (5 Rings &Lantern Ring) |
Graphite |
BT-052153500 |
052153500 |
G0006010 |
720440 |
|
1 |
Teflon Packing, Shaft (5 Rings & Lantern Ring) |
Teflon |
BT-052153502 |
052153502 |
G0006012 |
720500 |
|
1 |
Kevlar Packing, Shaft (5 Rings & Lantern Ring) |
Kevlar |
BT-052153400 |
052153400 |
G0006011 |
720470 |
|
2 |
Bolt assy,gland |
Stl 304 |
BT-052137280 |
052137280 |
G0006014 |
720600 |
|
1 |
Shaft |
40Cr |
BT-052133900 |
052133900 |
G0006002 |
721227 |
|
1 |
Sleeve,shaft,M.S. |
S.S.316 |
BT-052137001 |
052137001 |
|
721580 |
|
1 |
Sleeve,shaft,Pack |
Ceramic Coated |
BT-052144200 |
052144200 |
G0006015 |
|
|
1 |
Key,shaft |
Stl |
BT-WWW00A004 |
WWW00A004 |
|
721270 |
|
1 |
Seal, shaft sleeve |
Viton |
BT-WWB225V40 |
WWB225V40 |
G0006036 |
721490 |
|
1 |
Deflector assembly |
Composite |
BT-WWW003003 |
WWW003003 |
G0006006 |
721040 |
|
1 |
Frame, grease lubricated |
Cast iron |
BT-052136610 |
052136610 |
G0006001 |
|
|
3 |
Bolt, casing jack |
Stl. |
BT-WWG31S28F |
WWG31S28F |
|
|
|
1 |
Cover, inboard bearing |
Iron |
BT-052136710 |
052136710 |
G0006007 |
720780 |
|
1 |
Gasket,I.B.Brg.Cover |
fiber |
BT-052137400 |
052137400 |
G0006042 |
720670 |
|
1 |
Oil seal, I.B.Brg.Cover |
Buna-n |
BT-WWW003002 |
WWW003002 |
G0006038 |
720380 |
|
2 |
Bolt, I.B.Brg.Cover 1/2”-13 x 1 1/2” Long |
Stl |
BT-WWG31H1H7 |
WWG31H1H7 |
|
720891 |
|
2 |
Nut, I.B.Brg.Cover |
Stl |
BT-WWJ31H800 |
WWJ31H800 |
|
720902 |
|
1 |
Exclusion seal, I.B.Brg.Cvr. |
Bura-n |
BT-WWW003001 |
WWW003001 |
G0006039 |
720370 |
|
1 |
Bearing,inboard |
|
BT-WWENT5313 |
WWENT5313 |
G0006005 |
720300 |
|
1 |
Housing,O.B.bearing |
Iron |
BT-052136810 |
052136810 |
G0006003 |
720800 |
|
1 |
Seal, O.B.Brg.housing |
Buna-n |
BT-WWB254H30 |
WWB254H30 |
G0006043 |
721510 |
|
4 |
Bolts, O.B.Brg.housing 1/2”-13 x 1 1/2” Long |
Stl |
BT-WWG31H1H7 |
WWG31H1H7 |
|
720890 |
|
2 |
Nut, O.B.Brg.housing jam 1/2”-13 jam nut |
Stl |
BT-WWJ31H800 |
WWJ31H800 |
|
720970 |
|
1 |
Cover,O.B.Bearing |
Iron |
BT-052136910 |
052136910 |
G0006009 |
720790 |
|
1 |
O-ring, O.B.Brg.Cover |
Buna-n |
BT-WVIN00262 |
WVIN00262 |
G0006044 |
721520 |
|
1 |
Oil seal, O.B.Brg.Cover |
Buna-n |
BT-WWB248P41 |
WWB248P41 |
G0006040 |
720390 |
|
2 |
Bolt, O.B.Brg.Cover 3/8-16 x 1” Long |
Stl |
BT-WWG31D107 |
WWG31D107 |
|
720910 |
|
2 |
Bearing, O.B. |
Vendor |
BT-WWESK7311 |
WWESK7311 |
G0006008 |
720320 |
|
1 |
Lockwasher,O.B.Bearing |
Stl |
BT-WV00W1100 |
WV00W1100 |
|
721550 |
|
1 |
Locknut, O.B.Bearing |
Stl |
BT-WV00N1100 |
WV00N1100 |
|
721560 |
|
1 |
Fluid End Gasket Kit |
|
BT-052145400 |
052145400 |
G0006033 |
|
|
1 |
Power End Gasket Kit |
|
BT-052145500 |
052145500 |
G0006041 |
|
|
1 |
Oil Seal Kit |
|
BT-052149000 |
052149000 |
G0006037 |
|
|
1 |
Locknut Kit |
|
BT-052145700 |
052145700 |
G0006045 |
|
|
1 |
Sleeve, Shaft Repair Kit |
|
BT-052137000 |
052137000 |
|
|
|
1 |
Casing, 3×2×13 |
Hard Iron |
BT-052134000 |
052134000 |
G0006025 |
|
|
1 |
Casing, 4×3×13 |
Hard Iron |
BT-052134100 |
052134100 |
G0006026 |
|
|
1 |
Casing, 5×4×14 |
Hard Iron |
BT-052134200 |
052134200 |
G0006027 |
|
|
1 |
Casing, 6×5×11 |
Hard Iron |
BT-052134300 |
052134300 |
G0006028 |
|
|
1 |
Casing, 6×5×14 |
Hard Iron |
BT-052134400 |
052134400 |
G0006029 |
|
|
1 |
Casing, 8×6×11 |
Hard Iron |
BT-052134500 |
052134500 |
G0006030 |
|
|
1 |
Casing, 8×6×14 |
Hard Iron |
BT-052134600 |
052134600 |
G0006031 |
|
|
1 |
Impeller, 3×2×13 |
Hard Iron |
BT-05213571XS |
05213571XS |
G0006018 |
|
|
1 |
Impeller, 4×3×13 |
Hard Iron |
BT-05213581XS |
05213581XS |
G0006019 |
|
|
1 |
Impeller, 5×4×14 |
Hard Iron |
BT-05213591XS |
05213591XS |
G0006020 |
|
|
1 |
Impeller, 6×5×11 |
Hard Iron |
BT-05213501XS |
05213501XS |
G0006021 |
|
|
1 |
Impeller, 6×5×14 |
Hard Iron |
BT-05213621XS |
05213621XS |
G0006022 |
|
|
1 |
Impeller, 8×6×11 |
Hard Iron |
BT-05213601XS |
05213601XS |
G0006023 |
|
|
1 |
Impeller, 8×6×14 |
Hard Iron |
BT-05213631XS |
05213631XS |
G0006024 |
|
